School Wired Smart Natural Gas Alarm Detector CH4 Methane

School Wired Smart Natural Gas Alarm Detector CH4 Methane

Products - Gas Alarm Detector
  • High Light

    265V School Gas Alarm Detector

    ,

    Wired CH4 Gas Alarm Detector

    ,

    CH4 Methane natural gas detector

  • Name
    Gas Leakage Alarm
  • Application
    CH4 Methane LPG Propane
  • Feature
    Low Power Consumption
  • Warranty
    1 Year
  • Alarm Type
    Sound+Light Alarm
  • Color
    White
  • Lifespan
    5 Years
  • Working Voltage
    AC90V~265V
  • Alarm Volume
    70dB
  • Net Weight
    Net Weight 100g
  • Sensor Type
    Semiconductor
  • Detecting Range
    0~100% LEL
  • Presetting Alarm
    7% LEL(optional)
  • Working Environment
    Temperature: 0 ~ 40℃ Humidity: <95%RH (No
  • Warm-up Time
    180S
  • OEM/ODM
    Supported
  • E-Mail
    Sales@wgsensor.com
  • WhatsApp
    +8613333637163
  • Place of Origin
    China
  • Brand Name
    WG Sensor™
  • Certification
    CE
  • Model Number
    N1
  • Minimum Order Quantity
    5/pcs
  • Price
    17.5USD/1-10pcs~16.5USD /11+pcs(Negotiable)
  • Packaging Details
    Carton
  • Delivery Time
    5-10 working days
  • Payment Terms
    T/T, Western Union, MoneyGram, L/C
  • Supply Ability
    1000000 pcs per year

School Wired Smart Natural Gas Alarm Detector CH4 Methane

  • School Wired Smart Natural Gas Alarm Detector CH4 Methane
  • School Wired Smart Natural Gas Alarm Detector CH4 Methane
  • School Wired Smart Natural Gas Alarm Detector CH4 Methane
Get Price Contact Now

Wired Smart Natural Gas (CH4, Methane) Propane Gas Alarm Detector For Kitchen Hotel Restaurant SchoolApartment



Product Introduction



Airradio natural gas detector is for natural gas.If there is gas at home,once the concentration of the detected gas reaches the dangerous value,the detector will send out the audible and visual alarm singal,prompting you to take effective measures quickly to eliminate the danger and effectively avoid the accidents such as fire and explosion.



Features of the product



99.9% gas sensing platinum electrode, highly resolution to avoid false alarm;

Ring alarm indicator design;

Low power consumption, 2KWH per year;

Alarm-Sound, light





Specification



Model                                  N1
Target Gas               Natural gas ( CH4, Methane)
Working Environment

            Temperature: 0 ~ 40 degree Celsius

             Humidity: <95%RH (No Condensation)
Gas Sampling              Natural diffusion
Detecting Range              0~100% LEL
Presetting Alarm Level              7% LEL
Warm Up Time              180±10S
Sensor Type              Semiconductor
Lifetime              5 Yeas
Working Voltage             AC90V~265V
Weight              190g
Dimension              Diameter 90mm
Alarm Method              Visual and audible
Alarm Volume              70dB



Details



School Wired Smart Natural Gas Alarm Detector CH4 Methane 0School Wired Smart Natural Gas Alarm Detector CH4 Methane 1School Wired Smart Natural Gas Alarm Detector CH4 Methane 2



Manual



Installation Instructions
Installation location:
1)The detector and gas source should be located in the same indoor space.
2)The detector distance may be 1~3 meters away from the possible gas leak source is the best.
3)The detector should be installed less than 30cm from the ceiling.
Kitchen installation illustration
School Wired Smart Natural Gas Alarm Detector CH4 Methane 3
Maintenance

1) After storage and long time transport, the first time in use needs electricity aging more than 24 hours in
order to achieve the best performance.
2) During the usage period, activate the self-test at least once six month to confirm that the device works
normally. In the case of safety, please use a known concentrate gas for impacting test to confirm that the
device work normally.
3) It’s suggested to clean the shell of the combustible gas detector frequently to prevent its air hole being
blocked by dust. When cleaning the shell of the device, use clean soft brush or dry fluffy cloth without
detergent, decolorizer and polish. Cut off power supply when cleaning the shell.
4) N1 is designed for indoor use only. Please avoid contacting with rain, moisture, also need to avoid
drop. Do not beat, open or modification it, otherwise it may lead to product failure.
5) The detector should not be used near the volatile substance such as alcohol, hair gel, etc.
If false report caused, please open the ventilation device to make sure the detector return to normal detecting conditions.
6) Under normal circumstance, the service is 5 years. Please replace with new ones if exceed the
lifespan.
