indoor ambient monitoring CO2 PM2.5humidity temperature air quality monitor for home office hospital school
Descriptions:
AM100 series is a compact indoor ambience monitoring sensor for measurement of temperature, humidity, light, CO2 concentration, TVOC, barometric pressure and motion. These data will be shown on the E-ink screen in real-time, which allow to quantify the indoor environment and comfort. AM100 series is widely used for offices, stores, classrooms, hospitals, etc.
Features:
Technical Specifications:
| Model | AM100 Series | |
| Wireless Transmission | ||
| Technology | LoRaWAN® | |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923 | |
| Tx Power | 16dBm(868)/20dBm(915)/19dBm(470) | |
| Sensitivity | -137dBm @300bps | |
| Mode | OTAA/ABP Class A | |
| Sensors | ||
| Temperature | ||
| Range | -20°C to + 70°C | |
| Accuracy | 0°C to + 70°C (+/- 0.3°C), -20°C to 0°C (+/- 0.6°C) | |
| Resolution | 0.1°C | |
| Humidity | ||
| Range | 0% to 100% RH | |
| Accuracy | 10% to 90% RH (+/- 3%), below 10% and above 90% RH (+/- 5%) | |
| Resolution | 0.5% RH | |
| PIR | ||
| Detection Area | 94 ° Horizontal, 82 ° Vertical | |
| Detection Distance | 5 m | |
| Output Range | 0-65535 | |
| Light | ||
| Range | 60000 lux (Visible + IR, IR) | |
| Accuracy | ±30% | |
| Carbon Dioxide (CO2) | ||
| Range | — | 400 - 5000 ppm |
| Accuracy | — | ± (30 ppm |
| Resolution | — | 1 ppm |
| TVOC | ||
| Range | — | 0 - 60000 ppb |
| Accuracy | — | ±15 % |
| Resolution | — | 1 ppb |
| Long-term Stability | — | 1.3 % accuracy drift per year |
| Barometric Pressure | ||
| Range | — | 300 - 1100 hPa (-40°C - 85°C) |
| Accuracy | — | ±1 hPa |
| Resolution | — | 0.1 hPa |
| Display & Configuration | ||
| Display | 2.13-inch Black & White E-Ink Screen | |
| Configuration |
1. Mobile App via NFC 2. PC software via NFC or USB Type-C port |
|
| Physical Characteristics | ||
| Power Supply | 2 × 1.5V AA Alkaline Batteries or Type-C Port | |
|
Battery Life (10 min interval) |
Around 1.5 year | Around 1 year |
| Operating Temperature | 0°C to +45°C | |
| Relative Humidity | 0% to 100% (non-condensing) | |
| Ingress Protection | IP30 | |
| Dimension | 105 × 70.4 × 21.2 mm (4.1 × 2.8 × 0.8 in) | |
| Installation | Wall Mounting | |
| Approvals | ||
| Regulatory | CE, FCC, RoHS, LoRaWAN® Certified | |
| EMC | EN 55032, EN 55035 | |
| EMS |
IEC 61000-4-2 Level 3 IEC 61000-4-3 Level 2 IEC 61000-4-4 Level 4 IEC 61000-4-5 Level 3 IEC 61000-4-6 Level 3 IEC 61000-4-8 Level 4 |
|
| Radio Frequency |
FCC Part 15B, FCC Part 15.247, EN 300 330,EN 301 489-1/3, EN 300 220-1/2 |
|
| Safety | EN62368-1 | |
Test under laboratory conditions and for guideline purposes only.
Product details:
Company profile:
Henan Weiguo Intelligent Technology Co., LTD., founded in 2015, is an important subsidiary of Hanwei Electronics Group Corporation (Stock no.:300007) in the field of intelligent healthy, safe home and IoT business. Henan Weiguo Intelligent Technology Co., LTD., relying on the core sensor technology, focuses on gas and smoke alarm, air quality monitor, alcohol tester and firefighting products. Based on introduction of featured technology from both Hanwei Electronics Group Corporation and abroad, Henan Weiguo intelligent Technology Co., LTD., has developed into an innovative company with the collection of design, R&D development, production, sales and service. We will always be committed to becoming the leader in intelligent hardware, providing safe, healthy, environmentally friendly and intelligent working and living environment for families and users all over the world.
(Hanwei Electronics Group Corporation (Stock no.:300007), founded in 1998, is an influential manufacturer of gas sensors and instruments in China and a leading supplier of sensor-based IoT solutions in China. Hanwei Electronics Group Corporation is committed to providing perfect solutions for smart city, safe production, environmental protection and people's health.)
Our products are sold all over the world, you can rest assured.
