Scad-200 small air station for outdoor air quality monitor TVOC ,temperature , humidity , particulate matter ,
Description:
The system can monitor PM2.5 and PM10, temperature, humidity, wind speed, wind direction, VOCs, sulfide (H2S), amine (NH3), and other pollutants(expandable) in the environment. The system pushes the collected data to the on-site display screen in real time for reference of on-site personnel, and upload it to the cloud platform of the system. The platform will conduct big data analysis according to the data collected from various points, dig out the law of atmospheric quality change, and provide strong data support for macro control policies.
Features:
- Easy for installation
- Solar power supply
- Clamp or bracket installation
- Wireless data transmission
- Cloud services on the Big Data computing
- Real-time monitoring
- High accuracy
- Real-tie data transmission
- High ingress protection, suitable for outdoor use
- Cloud processing technology is adopted in the background, and the platform collects a large amount of data for comprehensive analysis.
Technical Parameters:
- Power supply: Solar (with backup battery)
- Working time: >300h (continuous working at 20℃)
- Working temperature: -30 to 60℃
- Working humidity: ＜95%RH (No condensation)
- Sensor life: 2 years
- Weight: About 40kg
- PM sensor type: Laser sensor
- Speed/direction sensor: Mechanical sensor
Sensor data:
| Sensor |
Range
|
Resolution
|
Accuracy
|
Ramark
|
| PM2.5 |
0-1000μg/m3 |
1μg/m3 |
±10%FS |
Standard |
| PM10 |
0-1000μg/m3 |
1μg/m3 |
±10%FS |
Standard |
| SO2 |
0-1000μg/m3 |
1μg/m3 |
±10%FS |
Standard |
| NO2 |
0-1000μg/m3 |
1μg/m3 |
±10%FS |
Standard |
| CO |
0-5000μg /m3 |
1μg/m3 |
±10%FS |
Standard |
| O3 |
0-1000μg/m3 |
1μg/m3 |
±10%FS |
Standard |
| Temp. |
-40℃-70℃ |
1℃ |
±1℃ |
Standard |
| Hum. |
10-95%RH |
1%RH |
±2%RH |
Standard |
| Speed |
0-30m/s |
0.1m/s |
±0.3m/s |
Standard |
| Direction |
0°-360° |
1° |
±1° |
Standard |
| TSP |
0-20mg/m3 |
1ug/m3 |
±10%FS |
Optional |
| Noise |
30-130dB |
1dB |
±10%FS |
Optional |
Application:
Mode of Transportation:
Company Profile:
Henan Weiguo Intelligent Technology Co., LTD., founded in 2015, is an important subsidiary of Hanwei Electronics Group Corporation (Stock no.:300007) in the field of intelligent healthy, safe home and IoT business. Henan Weiguo Intelligent Technology Co., LTD., relying on the core sensor technology, focuses on gas and smoke alarm, air quality monitor, alcohol tester and firefighting products. Based on introduction of featured technology from both Hanwei Electronics Group Corporation and abroad, Henan Weiguo intelligent Technology Co., LTD., has developed into an innovative company with the collection of design, R&D development, production, sales and service. We will always be committed to becoming the leader in intelligent hardware, providing safe, healthy, environmentally friendly and intelligent working and living environment for families and users all over the world.
