PM CO2 Humidity Temperature indoor air quality monitor
Descriptions
Air Quality Monitor AirRadio ABH103 is easy to operate, It can be widely used in household , office , hospital , school , car and many other applications where the air quality is important.
Technical Specifications
|
Working Environment
|
Temperature: 0 ~ 40℃ Humidity: <95%RH (No condensation) |
| Display |
LED |
| Battery Capacity |
1000mA, 3.7V |
| Sensor Type |
NDIR/Semi-conductor |
| Sampling Time |
4S |
| Power Supply |
DC5V/1A |
| Resolution |
CO2:3ppm;Temperature:1℃;Humidity:1% |
| Working Voltage |
AC90V~265V |
| CO2 Range |
400-5000ppm |
| Alarm Volume |
70dB |
| Temperature range |
0-±60℃ |
| Humidity range |
10-99% |
| Size |
80*50*80mm |
| Weight |
110g |
Power Charging
The product has a built-in lithium battery, which can be charged with the supporting USB power cord or Android mobile phone
cable. Connect one end of the power cord to the product's USB port and another end to the mobile phone charger/power bank/computer to charge. When the power is off, plug in the USB charging, it will automatically turn on.
The battery level is displayed in the upper right corner of the interface after power on.
Green: 50-100% electric c quantity
Yellow: 25-50% electric c quantitypower
Red: 10-25% electric c quantity
Automatic shutdown when less than 10%
Carbon Dioxide Detection
Detection principle: NDIR/semiconductor Resolution: 3ppm
Sampling time: 4 seconds Effective range: 400~5000ppm
Temperature and Humidity Detection
Temperature range: 0~+60C Humidity range: 10~99%
Temperature resolution: 1"C Humidity resolution: 1%
Product details:
Common Questions
Q: Why is the detector black screen?
Answer: It may be that the power of the detector is insufficient,and the automatic protection shuts down and needs to be charged. The blue charging indicator will flash when it is turned off and charged.
Q: Why does the detector consume more power?
Answer: The carbon dioxide sensor consumes a lot of power when working
Q: What are the precautions for carbon dioxide?
Answer: Excessive carbon dioxide concentration (more than 1500ppm) will affect the brain development of newborns, make adults drowsy, and seriously reduce work efficiency.Do not trigger the calibration function of the detector indoors, it will cause abnormal carbon dioxide readings and need to be recalibrated outdoorsThe unit of carbon dioxide is ppm. 1ppm means the volume ratio of CO2 in the air is one part per million, and 1ppm is converted to 1.98mg/m3 under standard conditions.
Q: How to calibrate to be accurate?
Answer: The detector has been calibrated before leaving the factory. During use, the instrument will be automatically calibrated according to the carbon dioxide concentration in the environment at regular intervals.
